12-8
13
11
F5
Moving the Machine [Fitted with ‘860’ controls]
n DANGER
Extreme care must be used when
manoeuvring the machine with the
umbilical control. Stand as far away as
possible. Do not allow the cable of the
hand set to sag and become entangled
with the tracks.
13. The directional control buttons are double
pressure switches. The initial pressure 1
operating the slow speed mode and second
pressure 2 operates the faster speed.
PRESS BUTTON TO MOVE
RELEASE BUTTON TO STOP MOVEMENT
14. Press the buttons to manoeuvre the machine in
the desired direction.
15. Release the buttons to stop movement.
NOTICES
If the machine is being moved using the
radio remote control and moves out of the
operating range of the radio or the battery
becomes discharged, the engine and
machine will stop.
Pressing the stop button on the radio or
umbilical control will immediately halt the
operation and cut out the engine but it
is necessary to manually switch o the
engine ignition.
11. Some machines can be driven with dierent
engine speeds which provides two speed
ranges. Select range to suit requirements, the
slow speed in high range is equal to the fast
speed in slow range.
12. Only use the faster speed where safe to do
so. Use the slower speed for more accurate
manoeuvring.
