17-8
1
1
2
3
3
Preparing to Crush
2. Connect suitable lifting shackles and lifting
equipment to the lifting points on the safety gate
and raise the safety gate from the transport
position to the working position.
Crusher Safety Grid
3. Secure the safety gate in the working position by
tting the securing bolts.
1. Locate the 2 lifting points on the safety gate.
(Illustration for showing the lifting points
only).
NOTICE
Ensure that suitable lifting equipment is
used when putting the safety gate into the
working position. Under NO circumstances
should the safety gate be lifted manually.
To Next Page
