Powerscreen XA750S - Page 25

AM0010-1
13
14
15
16
17
18
19
Powerscreen Plants
EN
Span Calibration
12. With belt running empty at normal speed with test weights applied.
13. SELECT P388 .
14. INVOKE INITIAL SPAN ENTER “ 1 “.
15. CURRENT SPAN COUNT= ####.
16. SPAN CALCULATION - FREQUENCY COUNT
DISPLAYED.
17. SPAN DEVIATION= ##.
18. ZERO DEVIATION ACCEPTED - INITIAL
ZERO COUNT= ####.
19. RETURN TO RUN MODE.
