AM0011-2
1
2
3
Water Pump [if tted]
Controls
1. The water inlet is a hose connector for the
provision of suitable supply piping from a clean
water container close to the machine.
3. Whilst valve lever 2 is in the on position the
screw type valve can be used to regulate the
supply to the machine water system.
SKIN INJECTION
HAZARD
n DANGER
Refer to Safety Notices Section for relevent
warning and procedure
2. Initial on and o control of the pump is by means
of a three position valve lever.
