PP Systems CIRAS-2 User Manual

CFM Operation
CIRAS-2 Operator's Manual Version 2.04
- 105 -
When a CIRAS Record is taken, perform
For all Adaptation Types, when the CIRAS record is taken, you have the option to perform either an Fs or
a phiPSII at that point in time. If this is desired, click on Setup for the Calculation Options dialog.
If Response Curve, at end of level, perform
Actions taken before CIRAS changes control settings to from one Response Curve level to the next.
Default Adaptation
Calculations
Performed
Dark Adaptation
phiPSR
Fo‟
Far Red Adaptation
None
No Adaptation
None
Complete CFM Recording with
Actions taken before the Response Curve concludes. If ticked, the CFM can also perform a phiPSR at
the end of measurement. If this is desired, click on Setup for the Calculation Options dialog.
Default Adaptation
Calculations
Performed
Dark Adaptation
phiPSR
Fo‟
Far Red Adaptation
Fo‟
No Adaptation
None
Save Trace Data
If selected, the actual fluorescence values and calculations will be saved to a file for later reconstruction of
the calculations.
Include „Pre‟ and „Post‟ Data
If selected, pre and post data will also be saved. Pre and post data refers to data 3 seconds before and 3
seconds after a measurement is recorded.
Calculation Options
Same as described above under Setup. The user can set the timing and light sources for the calculation
required here.
Modulation Beam
Opens the Set CFM (Light Unit) Parameters dialog. The user has the ability to enable/disable the
modulating beam, set modulating level, and adjust gain.
