PP Systems CIRAS-2 User Manual

CIRAS RCS Menu Bar
CIRAS-2 Operator's Manual Version 2.04
- 37 -
All four recording methods will be described in detail in the section Observing and Recording Leaf Gas
Exchange on page 59. Please note that for Closed Systems, Recording operates differently. See for
example Measuring Soil Respiration with CIRAS-2 on page 127 for more details.
Begin
Opens the Select Recording Options dialog to name a new file or select an existing file, edit treatment
descriptions and select type of recording.
End
Select to terminate the recording session.
Start (Steady)
Allows the user to decide when to begin recording once the leaf has stabilized inside the leaf chamber.
Pause
Used to temporarily suspend recording, for example, to allow the leaf additional time to stabilize.
Single Record
Initiates a single measurement, similar to a Keypress.

PP Systems CIRAS-2 Specifications

General

Brand	PP Systems
Model	CIRAS-2
Category	Measuring Instruments
Language	English
