PP Systems CIRAS-2 User Manual

System Setup and Operation
CIRAS-2 Operator's Manual Version 2.04
- 42 -
Add Entry
To create additional Set Files click Add Entry Name and choose „Default SET Name 2‟ from the
dropdown list. In the resulting dialog click Yes to use the current parameters or No to create a unique set
of parameters. Edit the new entry as above.
Delete Entry
This removes the currently selected Set File and its parameter, graph and recording options.
Recording Options
Click the Recording Options button to set up the type of recording you wish to make. The same dialog is
also available by selecting Recording – Begin. For a detailed description see Select Recording Options
on page 60.
Graphing Options
Click the Graphing Options button to change various options associated with graphical presentation of
data in the Graph Preferences dialog. The same dialog is available by selecting Setup – Graphing –
Preferences from the CIRAS menu bar. For a detailed description see Graphing Preferences on page
57.
PRM File Options
In the „PRM Entry Name‟ field select „Default PRM Name 1‟ from the dropdown list. Up to 10 parameters
settings per Set File are allowed.
PRM Entry Name
Select „Default PRM Name 1‟ from the dropdown list.
Edit Entry Name
Click on Edit Entry Name. Enter a short descriptive name in the Rename dialog, .e.g. the
cuvette/chamber used in your measurements.
Add Entry
To create additional PRM Files click Add Entry Name and choose „Default PRM Name 2‟ from the
dropdown list. In the resulting dialog click Yes to use the current parameters or No to create a unique set
of parameters. Edit the new entry as above.
