Observing and Recording Leaf Gas Exchange
CIRAS-2 Operator's Manual Version 2.04
- 77 -
Repeat
If „Enable Repeat‟ is checked, the software will repeat the Response Curve for the defined number of
repeats from 2 to 10 times. If unchecked, the Response Level only runs once.
CIRAS Internal Recording
If required, data can be saved directly onto CIRAS-2 memory. From the menu bar select Utilities -
CIRAS Recording to record measurements internally to CIRAS-2. The maximum number of records that
can be stored internally is 820. The following dialog box will appear:
Click on the “Enable Internal Recording” box and enter the value required in the “Record Interval” box.
Please note: The value you enter will be that value x 10. In other words, if you want to record every 60
seconds, enter 6 in this box and click on the Apply Internal Recording button. Then, click OK and
readings will be taken automatically at the recording interval that was set. To terminate CIRAS-2 Internal
Recording, return to Utilities - CIRAS Recording and click on “Enable Internal Recording” to disable it.
Please note the following: Unlike normal recording (i.e. Keypress, Timed Recording, etc.) where record
marks are displayed to show when a measurement is being recorded, you will not see any marks or ticks
on the display when readings are taken.
