CIRAS-2 Operator's Manual Version 2.04
- 36 -
Max C Determination
Allows Calculation/Resetting and checking of maximum CO
2
value.
Please note that CIRAS-2 Firmware (EPROM) Version 1.67 or greater is required for this
functionality. If unsure of firmware version, see View – Quick Info in the CIRAS menu bar.
It is important that CIRAS-2 has been turned on for 20 minutes and that the CO
2
cartridge is full and the
chemicals fresh. Additionally, a special T-Piece must be fitted to CIRAS-2 prior to starting the CO
2
Midpoint setting. Refer to Max C Determination on page 149 for further details.
LED Tuning
Allows manual LED tuning (automatic LED Tuning performed during start up) and recalls Tuning results.
See LED Tuning on page 25 for details.
CIRAS Recording
Enable/Disable CIRAS-2 Internal Recording. Save up to 820 internal records to CIRAS-2 and initiate a
stored data dump from this menu. Please note that this is different than the normal CIRAS-2 recording
mode. See CIRAS Internal Recording on page 77 for additional details.
Recording Menu
To begin measurements select Recording - Begin. There are four recording methods available with
CIRAS-2:
Key Press
Timed
Response Curve
Batch Response Curve
