Diagnostics
CIRAS-2 Operator's Manual Version 2.04
- 140 -
Right Battery Voltage
Refers to the current state of charge of the right battery. When fully charged, it should read > 13V.
Current Battery/Power Source
Refers to the source of power for CIRAS-2, whether it is battery (left or right) or the external power supply.
When the voltage of one battery drops to approx. 10.5V, the CIRAS-2 automatically switches over to the
other battery (if fitted).
Report
A final report can be generated to provide PP Systems with a general summary of the diagnostic data.
Again, this information is very helpful for technical support purposes. It contains important information
such as CIRAS-2 serial number, hardware, eprom version, date and time, analyzer (reference and
analysis) A/D reads, etc. A file may also generated that can be emailed to us for analysis.
Quick Report
Generates a baseline set of information about the functional state of analyzers, pumps, valves, board
electronic and accessories. Click Save and select a folder location for the resulting .txt file. The file may
be useful to PP Systems Technical Support. A completed Diagnostics „Quick‟ Report dialog is shown
below.
Extended Report
Performs, in a semi-automated fashion, a thorough set of routines to establish the state of the CIRAS-2
system. Two major 'sections', 'Analyser Tests' and' Leaf Chamber Tests'. It is recommended that both
