The maximum file size is 2 GB
The maximum file size is 2 GB. The
SD card needs to be the same size.
Record
A1681
New
DATALOG0.CSV
9.1.3.4.1
Fig. 110: Check the file to write it to an
existing file, here [DATALOG0.CSV]
3. If you wish to attached measured
data to an existing file, then check
this file and the data will be written
to this file
If the SD card is removed, then data can
be recorded for a maximum of 24 hours in
the controller's internal memory with a
storage interval of 10 seconds. Around six
times as long with an interval of 60 sec‐
onds. When the SD card is re-inserted
into the controller, then the data from the
internal memory is backed up to the SD
card. This can take up to 20 minutes if 24
hours of data has been recorded. The
green LED on the SD card reader flashes
red/orange during this time.
Function: Data logger
145
