Connection of the transmitter DTMa
A DMTa is connected to the controller as a 2-wire transmitter:
–
Terminal DACa, channel 1: XE4.3 minus pole and XE4.4 plus pole
–
Terminal DACa, channel 2: XE8.3 minus pole and XE8.4 plus pole
–
refer to: Ä ‘Main unit (channel 1) terminal diagram with assignment options ’
on page 36 and Ä ‘Extension unit (channel 2) terminal diagram with assignment
options ’ on page 38
An external manufacturer's transmitter
Connect an external manufacturer's transmitter as follows to the controller if the
transmitter delivers an active signal:
–
Terminal DACa, channel 1: XE4.3 plus pole and XE4.4 minus pole
–
Terminal DACa, channel 2: XE8.3 plus pole and XE8.4 minus pole
–
refer to: Ä ‘Main unit (channel 1) terminal diagram with assignment options ’
on page 36 and Ä ‘Extension unit (channel 2) terminal diagram with assignment
options ’ on page 38
Assembly and installation
