PLX32-EIP-MBTCP-UA ♦ Multi-Protocol Gateway MBTCP Protocol
User Manual
ProSoft Technology, Inc. Page 105 of 156
March 8, 2018
Supported Function Codes
The format of each command in the list depends on the Modbus Function Code
being executed. The following table lists the Function Codes supported by the
PLX32-EIP-MBTCP-UA.
Function Code
Definition
Supported as master
Supported as server
1
Read Coil Status 0x
X
X
2
Read Input Status 1x
X
X
3
Read Holding Registers 4x
X
X
4
Read Input Registers 3x
X
X
5
Set Single Coil 0x
X
X
6
Single Register Write 4x
X
X
8
Diagnostics
X
15
Multiple Coil Write 0x
X
X
16
Multiple Register Write 4x
X
X
17
Report Slave ID
X
22
Mask Write 4X
X
23
Read/Write
X
Each command list record has the same general format. The first part of the
record contains the information relating to the communication gateway and the
second part contains information required to interface to the Modbus server
device.
