ProSoft PLX32-EIP-MBTCP-UA - 4 Hardware Information; 4.1 Hardware Specifications

PLX32-EIP-MBTCP-UA ♦ Multi-Protocol Gateway Hardware Information
User Manual
ProSoft Technology, Inc. Page 39 of 156
March 8, 2018
4 Hardware Information
4.1 Hardware Specifications
Specification
Description
Power Supply
24 VDC nominal
10 to 36 VDC allowed
Positive, Negative, GND Terminals
Current Load
24 VDC nominal @ 300 mA
10 to 36 VDC @ 610 mA maximum
Operating Temperature
-25°C to 70°C (-13°F to 158°F)
Storage Temperature
-40°C to 80°C (-40°F to 176°F)
Relative Humidity
5% to 95% RH with no condensation
Dimensions
(H x W x D)
5.38 x 1.99 x 4.38 in
13.67 x 5.05 x 11.13 cm
LED Indicators
 Configuration (CFG) and Error (ERR) Communication Status
 Power (PWR) and Hardware Fault (FLT)
 Network Status (NS) EtherNet/IP™ Class I or Class III Connection
Status (EtherNet/IP Only)
 Module Status (MS) Module Configuration Status (EtherNet/IP Only)
 Ethernet Communication Port Link/Activity and 100 mbit
Ethernet Port(s)
10/100 Mbit full-duplex RJ45 Connector Electrical Isolation 1500 Vrms at
50 Hz to 60 Hz for 60 seconds, applied as specified in section 5.3.2 of IEC
60950: 1991
Ethernet Broadcast Storm Resiliency = less than or equal to 5000 [ARP]
frames-per-second and less than or equal to 5 minutes duration
Shipped With Each
Unit
2.5 mm screwdriver
J180 Power Connector
