5.3 Network Diagnostics
5.3.1 EIP PCB Diagnostics
The best way to troubleshoot the EIP driver is to use ProSoft Configuration
Builder to access the diagnostic capabilities of the gateway through the Ethernet
debug port.
The following table summarizes the status information available in PCB for the
EIP driver:
Connection Type
Submenu Item
Description
EIP Class 1
Config
Configuration settings for Class 1 Connections.
Status
Status of the Class 1 Connections. Displays any configuration
error, as well as the number of Class 1 Connections.
EIP Class 3 Server
Config
Configuration settings for Class 3 Server Connections.
Comm Status
Status information for each Class 3 Server Connection.
Displays port numbers, IP addresses, socket status, and read
and write counts.
EIP Class 3
Client/UClient [x]
Config
Configuration settings for Class 3 Client/UClient Connections.
Comm Status
Status information for Class 3 Client/UClient [x] commands.
Displays a summary of all the errors resulting from Class 3
Client/UClient [x] commands.
Commands
Configuration for the Class 3 Client/UClient [x] command list.
Cmd Errors
(Decimal)
Current error codes for each command on the Class 3
Client/UClient [x] command list in decimal number format. A
zero means there is currently no error for the command.
Cmd Errors
(Hex)
Current error codes for each command on the Class 3
Client/UClient [x] command list in hexadecimal number format.
A zero means there is currently no error for the command.
For specific information on error codes, see EIP Error Codes (page 67).
