PLX32-EIP-MBTCP-UA ♦ Multi-Protocol Gateway EIP Protocol
User Manual
ProSoft Technology, Inc. Page 57 of 156
March 8, 2018
Parameter
Value
Description
File Type
Binary
Counter
Timer
Control
Integer
Float
ASCII
String
Status
Specifies the file type to be associated with the command.
File Number
-1
Specifies the SLC 500 file number to be associated with the
command. If a value of -1 is entered for the parameter, the field will not
be used in the command, and the default file will be used.
Element
Number
Specifies the element in the file where the command will start.
Sub
Element
Specifies the sub-element to be used with the command. Refer to the
AB documentation for a list of valid sub-element codes.
Comment
Optional 32 character comment for the command.
