ULTRA 4 INSTRUCTION MANUAL
72
If neither pump can cope, and the level rises to 2.38m (7.8 ft), then the alarm
relay (relay 3) will come on and go off when the level falls to 2.24m (7.34 ft).
This will indicate insufficient capacity of the pumps. The display will show
the level in the sump and the mA output will be representative of level
where 4mA = empty level (0%) and 20mA = 2.8m (9.18 ft) (100%).
To program the Ultra 4 for Example 5 Sump control (pump down) by
using the Quick Setup menu proceed as follows. If required to access
Program Mode, key in the passcode 1997 and press ENTER
At the Quick Setup menu press ENTER and as prompted, by the questions,
select the relevant option and ENTER.
QUESTION
OPTION
Level/Pump Up or Down
2 = Pump Down
No. of Pumps
2 = 2 Pumps
Pump Duty
3 =Alt Duty Assist
Pump No. 1
1 = Set to relay 1
Pump No. 2
2 = Set to relay 2
Type Alarm 1
1 = High Alarm
Alarm No. 1
The unit knows that only Relays 3 & 4
are available and will only display
these for use.
Xducer (P101)
2 = dB6
Measurement units (P104)
1 = Metres
Empty Level (P105)
3.5m
Span (P106)
2.8m
Programming is now complete, and the unit can be returned to the run
mode, press CANCEL until Run Mode? Is displayed on the LCD press
ENTER, and the Ultra 4 will return to the Run Mode.
Important Notice
If relay setpoints do not meet the exact requirements of the application, they can
be modified to suit by pressing ENTER when, “For More Options Hit Enter”, is
displayed, and entering new values to relay setpoints as required. Alternatively,
the relevant relay setpoint can be accessed either by the main menu system or
directly via parameter number and changed as necessary.
