ULTRA 4 INSTRUCTION MANUAL
74
be representative of level where 4mA = empty level (0%) and 20mA = 2.8m
(9.18 ft) (100%).
To program the Ultra 4 for Example 6 Reservoir Control (pump up) by
using the Quick Setup menu proceed as follows. If required access the
Program Mode and key in the passcode 1997 and press ENTER
Using the ‘right arrow key, go to Quick Setup menu press ENTER and as
prompted, by the questions, select the relevant option and ENTER.
QUESTION
OPTION
Level/Pump Up or Down
2 = Pump Up
No. of Pumps
2 = 2 Pumps
Pump Duty
3 =Alt Duty Assist
Pump No. 1
1 = Set to relay 2
Pump No. 2
2 = Set to relay 3
No. of alarms
1 = 1 alarm
Type Alarm 1
2 = Low Alarm
Alarm No. 1
The unit knows that only relay 1 is
available and so will automatically set
alarm 1 to Relay 1
Xducer (P101)
2 = dB6
Measurement units (P104)
1 = Metres
Empty Level (P105)
3.5m
Span (P106)
2.8m
Programming is now complete, and the unit can be returned to the run
mode, press CANCEL until Run Mode? Is displayed on the LCD press
ENTER, and the Ultra 4 will return to the Run Mode.
Important Notice
If relay setpoints do not meet the exact requirements of the application,
they can be modified to suit by pressing ENTER when, “For More Options
Hit Enter”, is displayed, and entering new values to relay setpoints as
required. Alternatively, the relevant relay setpoint can be accessed either
by the main menu system or directly via parameter number and changed
as necessary.
