Pulsar Ultra 4 User Manual

PULSAR MEASUREMENT
93
To program the Ultra 4 for Example 2 BS3680 U-Throated Flume by using
the Quick Setup menu proceed as follows. If required access the Program
Mode, key in the passcode 1997 and press ENTER. Using the ‘right’ arrow
key, go to the Quick Setup menu press ENTER and as prompted, select the
relevant option and press ENTER.
QUESTION
OPTION
PMD Type
2 = 3680 Flume
3680 Flumes
3 = U-Throat
Calculation
1 = Absolute
No. of alarms
1 = 1 Alarm
Type alarm 1
2 = Low
Alarm No.1
1 = Set to relay 1
Transducer
8 = dB Mach3
Volume units
2 = Cubic metres
Time Units
4 = Per hour
Measurement units
1 = Metres
Empty level
1.00m
Minimum head
0.00m
Maximum head
0.40m
Totaliser enabled
1 = On
Totaliser multiplier
7 = *1
Approach dia. (Dim A)
0.70m
Throat dia. (Dim B)
0.50m
Throat length (Dim C)
1.00m
Aux Line 2
13 = Tot R
Programming is now complete, and the unit can now be returned to the run
mode, press CANCEL until Run Mode? Is displayed on the LCD press
ENTER, and the Ultra 4 will return to Run Mode.
Important Notice
If relay setpoints do not meet the exact requirements of the application,
they can be modified to suit by pressing ENTER when, “For More Options
Hit Enter”, is displayed, and entering new values to relay setpoints as
required. Alternatively, the relevant relay setpoint can be accessed either
by the main menu system or directly via parameter number and changed
as necessary.
