To program the Ultra 4 for Example 3 BS3680 Weir by using the Quick
Setup menu proceed as follows. If required access the Program Mode, key
in the passcode 1997 and press ENTER.
Using the ‘right’ arrow key, go to the Quick Setup menu press ENTER and
as prompted, by the questions, select the relevant option and press ENTER.
QUESTION
OPTION
PMD Type
3 = 3680 Weir
3680 Weir
1 = Rectangular
Calculation
1 = Absolute
No. of alarms
1 = 1 Alarm
Type alarm 1
1 = High
Alarm No.1
1 = Set to relay 3
Transducer
8 = dB Mach3
Volume units
1 = Litres
Time Units
2 = Minute
Measurement units
1 = Metres
Empty level
1.00m
Minimum head
0.00m
Maximum head
0.40m
Totaliser enabled
1 = On
Totaliser multiplier
7 = 1000
Approach dia. (Dim A)
0.50m
Throat dia. (Dim B)
0.30m
Throat length (Dim C)
0.30m
Aux Line 2
13 = TotR
