6. RAID Setting Instructions 145
www.qtech.ru
Figure 6-7
5. Select Create Volume and press Enter to group the raid.
Related parameters are described in Table 1-28:
RAID level, which determines the performance, fault
tolerance and capacity of the logical disk.
Select the member disks that make up the RAID.
Available disks are displayed under the Select Disks
column, press Enter
Select the disk, [X] means that the disk has been
selected.
Stripe size, the size of striped data blocks written on
each disk.
The capacity of the logical disk.
Table 1- 23
After the RAID is created, it will be displayed under the RAID Volumes directory. Select
a RAID and press Enter to view the detailed information of the RAID (including RAID
name, level, and disk information, etc.).
❖ Configure hot spare disk
1. As shown in Figure 6-8, select the disk to be configured as a hot spare disk and
press Enter.
Figure 6-8 Select the disk to be configured as a hot spare disk
