Руководство пользователя
6. RAID Setting Instructions 209
www.qtech.ru
6.6 Locate the disk location:
This function is convenient for you to find the disk quickly by lighting the blue indicator
of the corresponding slot of the disk. A single physical disk or all member disks
included in a logical disk can be located.
1. As shown in Figure 6-121, select the disk to be located on the PD Mgmt interface
and press F2.
Figure 6-121 Select the disk to be located
Figure 6- 62
2. Enter the interface shown in Figure 6-122 and select Locate->Start to complete the
disk positioning operation.
Figure 6-122 Select Locate-〉Start
Figure 6-63
