Руководство пользователя
2. Product Introduction 19
www.qtech.ru
Internal storage: 2 SATA ports (7Pin), 2 PCIe 3.0
X2 M.2
Interface, 3 minisas 8643 interfaces, 2 slimline x8
interfaces
The front panel supports up to 8/12/hot-plug
3.5/2.5 inch SAS/SATA (HDD/SSD)
The rear supports 4*2.5" and 4*3.5" hard disks or
8*2.5"
Platinum 550W, 800W, 1200W, 1600W hot-
swappable redundant power
Source (adapted according to actual power)
Front port: 1 VGA; 2 USB3.0
Rear: 1 VGA, 1 DB-9COM port, 2 USB3.0, 1
RJ45 Gigabit management network port, 2
Gigabit/10 Gigabit RJ45 network ports
PCIE expansion: supports up to 11 PCIe3.0 slots
N+1 hot-swappable redundant fans
2 Gigabit/10 Gigabit RJ45 network ports
Support TPM module
Chassis opening intrusion detection
The onboard iBMC management module
supports IPMI, SOL, KVM Over IP,
Management features such as virtual media
Table 1-4
2.2.2 System structure
The dual-socket L-shaped server uses the Intel Purley platform with Intel® Xeon®
scalable processors; supports DDR4 LRDIMM/RDIMM/NV-DIMM ECC server memory,
and the memory frequency supports 2133/2400/2666/2933MHz; a single CPU supports
6 Two channels, each channel supports 2 DIMMs; two CPUs support a total of 24
DDR4 slots; supports a single capacity of 8GB, 16GB, 32GB, 64GB, 128GB.
The main board features are as follows:
❖ The CPU adopts the first and second generation Intel® Xeon® scalable processors,
LGA3647 socket, TDP power consumption 205W;
