7.1.3 IPMI interface configuration Static mode
If you choose to configure Static mode for the IPMI interface, you should pay attention
to the following issues:
1. If there are multiple IPMI devices in your local area network, please note that the IP
addresses between the devices cannot be repeated, otherwise communication
cannot be established.
2. If the IP of your IPMI device is an intranet address, the terminal device
communicating with it must be in the same network segment as the IPMI device
address.
3. The IP address of the IPMI device can be mapped to the WAN through the routing
device for remote management.
4. The IPMI port has the function of obtaining an IP address through DHCP.
5. IPMI supports two protocols, TCP/IP v4 and TCP/IP v6.
Configure the IP address and subnet mask according to your actual situation. For
example, here we set the IP address to 192.168.0.236 and the subnet mask to
255.255.252.0, as shown in Figure 7-7 below. After setting, press F4 to save and exit
the BIOS interface.
7.1.4 IPMI configuration Java SOL
1. Press the <Del> key when the system starts to enter the BIOS setting interface.
2. Switch to the Advanced menu, select Serial Port Console Redirection, and press
<Enter> key.
3. Make sure that the Console Redirection of COM0 is in the [Enabled] state, if not,
select Console Redirection, and then press the <Enter> key to set the state to
[Enabled]. To ensure the normal operation of iBMC, this option has been set to
[Enabled] by default.
