7 IPMI RAPID DEPLOYMENT
7.1 Rapid deployment of IPMI process
7.1.1 Make sure the motherboard supports IPMI function
Check your motherboard manual and confirm that your motherboard supports IPMI,
then find the dedicated IPMI network port for the motherboard, or you can choose to
share the network port, as shown in Figure 7-2.
Figure 7-2 Main board dedicated network port
7.1.2 Enter BIOS to set IPMI function
Restart your system and press ESC or DEL to enter the motherboard BIOS system
while the device is booting. The BIOS setting interface is shown in Figure 7-3.
Figure 7-3 Mainboard BIOS setting interface
After entering this interface, use the left and right keys of the keyboard to switch the
menu item to the Server Mgmt option, and you will see the page shown in Figure 7-4.
