4.2 Install the outer rail to cabinet
Step 3. Install the outer rail on the cabinet bracket and tighten the screws.
Note: When installing the guide rail, you need to align the U mark, and install it in place
with a snapping sound. Use M5 screws to secure it.
Figure 4-3
