Руководство пользователя
6. RAID Setting Instructions 200
www.qtech.ru
6.3 Configure RAID in Legacy Boot Mode
❖ Enter the RAID card configuration interface
1. During the BIOS startup process, after the interface shown in Figure 6-105 appears,
press Ctrl+R.
Figure 6-106 Press Ctrl+R as prompted during BIOS startup
Figure 6- 106
2. Enter the interface shown in Figure 6-107. Please refer to the key operation tips at
the lower border of the interface to navigate and modify settings in the interface.
Figure 6-107 LSI RAID management interface
Figure 6- 50
❖ Common tasks
Configure RAID:
3. As shown in Figure 6-108, press F2 on the VD Mgmt interface and select Create
Virtual Drive.
