Expansion
Card
1.(Left) PCI-Express 3.0 X24 slot comes from
CPU0;
2.(Middle) PCI-Express 3.0 X24 slot comes
from CPU0 / CPU1;
3.(Right) PCI-Express 3.0 X16 slot comes from
CPU1;
hard disk
Supports up to 8 front 3.5-inch/2.5-inch
SAS/SATA (HDD/SSD)
The rear can support 4 2.5-inch SAS/SATA
(HDD/SSD), 4 rear 3.5/2.5-inch SAS/SATA
(HDD/SSD)
Onboard 3*8643 interface, 2*SATA DOM
Optical
drive
Support 1 optical drive;
M.2 SSD
2 M.2 PCIE X2 (2280)
LAN
Onboard 2 Gigabit RJ45 data network ports
(optional 2 Gigabit RJ45 data
Network port)
External
port
Front port: VGA, 2 USB3.0
Rear: VGA, 2 USB3.0, 1 management network
port, 2 RJ45
Data network port, 1 DB-9 COM port
manageme
nt
The onboard iBMC management module
supports IPMI, SOL, KVM Over IP,
Management features such as virtual media
System fan
4 8038 brand fans (optional 4 8056 brand fans)
power
Standard platinum 550W, optional 800W,
