7.2.3.1 IPMI management interface menu description
1. dash board
On this page, users can view the basic information of the IPMI management system.
Including firmware information, network information, and sensor monitoring information.
The firmware information includes BMC firmware version information, BIOS version
information, motherboard CPLD version information, backplane CPLD version
information, and BMC firmware compilation time information.
The network information includes the MAC address of the system network and BMC
network information. You can choose to view the shared network port or dedicated
network port of the BMC. BMC network information includes BMC network MAC
address information, IPV4 network mode information, IPV4 address information, IPV6
network mode information, and IPV6 address information.
The sensor monitoring information will display the current alarm sensor information in
real time, including sensor name, sensor reading, real-time curve change of sensor
reading, and alarm status.
2. sensor
This page displays the status of all sensors. When there is a sensor alarm, the sensor
will be displayed in the key sensor column. When the alarm is released, the sensor will
be automatically removed from the key sensor column.
3. System list
This page can view server CPU and memory information. In the block diagram, click
the CPU block to view the CPU information. The memory block is displayed in green to
indicate that the memory exists. Click the memory block to view the memory
information.
4. Hard Disk Information
For the backplane with Expander, the green square means that the hard disk is in place,
otherwise it means it is not in place. You can view the status of the hard disk on the
right or below the hard disk block. Left click the green square to view the detailed
information of the hard disk, and right click to locate the hard disk.
5. Power consumption
Under this menu, the power consumption can be capped and the recent power
consumption can also be viewed.
6. FRU information
Select this menu to view the basic information of the FRU.
7. Log & Report
Under this menu, you can view the IPMI time log, audit log and video log.
8. Set up
You can configure some BMC under this menu. Including BSOD, date & time, network,
etc...
9. remote control
