Руководство пользователя
2. Product Introduction 30
www.qtech.ru
Table 1-12
❖ Description:
Both 1 and 2 can be equipped with rear hard disk modules or riser modules. This
picture is for reference only, and the actual configuration shall prevail.
❖ Rear panel interface description
Used to connect a display terminal,
such as a monitor or
KVM。
Provide an outgoing 1000Mbit/s
Ethernet port. The server can be
managed through this interface.
Provide an outgoing USB interface,
through which USB devices can be
connected.
note:
When using an external USB
device, make sure that the USB
device is in good condition,
otherwise it may cause the server
to malfunction.
Make an exception.
RJ45
Gigabit
Ethernet
port
Server service network port.
Power
module
AC
interface
You can choose the number of
power supplies according to your
actual needs, but you must ensure
that the rated power of the power
supply is large
It is the rated power of the whole
machine.
