Remote control commands
R&S
®
NRPxxP
71User Manual 1179.5760.02 ─ 02
1.00
0.00
dBm
-30.00
0.00
12
Figure 8-6: PDF measurement parameter
1 = Average power
2 = Peak power
For information on querying the measurement results, see Chapter 8.9.6, "Statistics
measurement results", on page 106.
8.6.6.1 Configuring the analysis window
Set the number of analysis window repetitions using SENSe<Sensor>:TRACe:
AVERage:COUNt. For defining start, length and exclusion period, use the following
commands:
SENSe<Sensor>:STATistics[:EXCLude]:MID:OFFSet[:TIME]................................................71
SENSe<Sensor>:STATistics[:EXCLude]:MID:TIME..............................................................71
SENSe<Sensor>:STATistics:OFFSet:TIME.........................................................................72
SENSe<Sensor>:STATistics:TIME..................................................................................... 72
SENSe<Sensor>:STATistics[:EXCLude]:MID:OFFSet[:TIME] <time>
Sets the start of an exclusion interval in the analysis window, referenced to the start of
the analysis window.
All other settings are the same as for the timeslot mode, see Chapter 8.6.3, "Timeslot
measurement", on page 59.
Parameters:
<time> Range: 0.0 to 0.3
*RST: 0.0
Default unit: s
SENSe<Sensor>:STATistics[:EXCLude]:MID:TIME <time>
Sets the length of an exclusion interval in the analysis window.
Configuring the measurement modes
