Remote control commands
R&S
®
NRPxxP
72User Manual 1179.5760.02 ─ 02
All other settings are the same as for the timeslot mode, see Chapter 8.6.3, "Timeslot
measurement", on page 59.
Parameters:
<time> Range: 0.0 to 0.3
*RST: 0.0
Default unit: s
SENSe<Sensor>:STATistics:OFFSet:TIME <time>
Sets the start of the analysis window for recording measured values. The start time is
referenced to the beginning of the actual measurement. If the analysis window starts
before the trigger event, you have to set a sufficient negative trigger delay using
TRIGger:DELay, at least the minimum value plus a safety margin of −51.2 µs.
Parameters:
<time> Range: 0.0 to 10.0
*RST: 0.0
Default unit: s
SENSe<Sensor>:STATistics:TIME <time>
Sets the duration of the statistics measurement.
Parameters:
<time> Range: 50.0e-9 to 53
*RST: 0.01
Default unit: s
8.6.6.2 Configuring the video bandwidth
See Chapter 8.6.4.1, "Configuring the video bandwidth", on page 62.
8.6.6.3 Triggering a statistics measurement
You can trigger the statistical analysis by INTernal, EXTernal or IMMediate trigger
sources. See Chapter 8.5.2.3, "Trigger sources", on page 43.
8.6.6.4 Querying the highest level resolution
SENSe<Sensor>:STATistics:SCALe:X:MPWidth?
Queries the highest level resolution that is attainable. The value is fixed at 0.006 dB
per pixel. If this value is not reached, the power sensor outputs a settings conflict mes-
sage.
Solutions for the conflict can be:
●
Select a smaller number of pixels using SENSe<Sensor>:STATistics:SCALe:
X:POINts.
Configuring the measurement modes
