5.SelectapresetZoomFactor(x2,x3,x4)orselectManual
OnceselectionismadeyouwillbereturnedtotheDisplayMode
menu.
6.IfManualischosenselectManualZoomFactor
Themanualzoomfactormenuisdisplayed.
7.SelectManualZoomFactorsothatthezoomsettingis
highlighted.
8.UsingtheRotaryControlchangethezoomfactortothe
requiredsetting.
9.PresstheOkbutton,orselecttheManualZoomFactormenu
againtoconrmthesetting.
Adjustingthepositionoftheshnderzoomedarea
Whenthezoomfunctionisselected,thesystemautomatically
selectsthezoompositionsothatthebottomdetailsarealwaysinthe
lowerhalfofthedisplay.Ifrequiredyoucanrepositiontheportionof
theimagetobezoomedsothatanalternativeareaisdisplayed.
Fromtheshnderapplication,withZoompresetselected:
1.SelectMenu.
2.SelectAdjustPreset<mode>,where<mode>isthepreset
alreadyselected.
3.SelectDisplayMode.
4.SelectZoomPosition.
Themanualzoompositionmenuisdisplayed.
5.SelectZoomPosition.
Selectingthezoompositionmenuwillswitchthezoomposition
betweenAutoandManual.
6.IfManualischosenusetheRotaryControltorepositionthe
zoomedareaasrequired.
FishnderA-Scopemode
TheA-Scopemodeenablesyoutoviewalive(ratherthanhistorical)
imageoftheseabedandshdirectlybelowyourvessel.
Thestandardshnderdisplayshowsahistoricalrecordofshnder
echoes.Ifrequired,youcandisplayaliveimageofthebottom
structureandtheshdirectlybelowthetransducerbyusingthe
A-Scopefeature.ThewidthofthebottomcoveredbytheA-Scope
isindicatedatthebottomofthewindow.A-Scopeprovidesamore
preciseandeasiertointerpretindicationofthetargetstrength.
TherearethreeA-Scopemodes:
Mode1Mode2Mode3
TheA-scopeimageis
centredinthewindow.
Theleft-handsideof
theMode1imageis
expandedtogiveamore
detailedview.
TheA-scopeimage
anglesoutwardas
signalwidthincreases
withdepth.
BottomLock
TheBottomLockfunctionappliesaltertoattentheimageofthe
seabedandmakeanyobjectsonorjustaboveiteasiertodiscern.
Thisfeatureisparticularlyusefulforndingshthatfeedcloseto
thebottom.
BottomLockisselectedforindividualshnderwindowsand
canreplaceorappearalongsidethestandardshnderimage.
Adjustingtherangeofthebottomlockimageallowsyoutoview
morebottomdetails.Youcanalsorepositiontheimageonscreento
anywherebetweenthebottomofthewindow(0%)andthemiddleof
thewindow(50%)byusingtheBottomShiftcontrol.
BottomLockisselectedforindividualshnderwindowsandcan
eitherreplace(ON)orappearalongside(SPLIT)thestandard
shnderimage.
Adjustingthebottomlockrange/position
Fromtheshnderapplication,withbottomlockdisplaymode
selected:
1.SelectMenu.
2.SelectAdjustPreset<mode>,where<mode>isthepreset
alreadyselected.
3.SelectDisplayMode.
4.SelectBottomLocktoswitchbetweenFullscreenandSplit
screen
5.SelectB-LockRange.
SelectingBottomLockRangewillopentheB-LockRangemenu
6.SelecttheB-LockRangemenu.
7.UsetheRotaryControltoadjusttherangetotherequired
setting.
8.PresstheOkbutton,orselecttheB-LockRangemenuagainto
conrmthesetting.
162e7/e7D/e95/e97/e125/e127/c95/c97/c125/c127
