Raymarine c97 Installation And Operation Handbook

4.10NMEA0183connection
D12 2 66 -1
61 2 3 4 5
11
7 8 9 10
12
NMEA DEVICE
4800 / 9600 / 38400 baud
NMEA DEVICE
4800 / 9600 / 38400 baud
NMEA0183devicesareconnectedusingthesuppliedpowerand
datacable.
Thedisplayhas2NMEA0183ports:
•Port1:Inputandoutput,4800,9600or38400baudrate.
•Port2:Inputonly,4800,9600or38400baudrate.
Note:Thebaudrateyouwanttouseforeachportinputmustbe
speciedintheSystemSettingsmenu(Homescreen:>Set-up
>SystemSettings>NMEASet-up>NMEAInputPort).
Note:ForPort1,boththeinputandoutputcommunicateatthe
samebaudrate.Forexample,ifyouhaveoneNMEA0183
deviceconnectedtothedisplay’sPort1INPUT,andanother
NMEA0183deviceconnectedtothedisplay’sPort1OUTPUT ,
bothNMEAdevicesmustbeusingthesamebaudrate.
Youcanconnectupto4NMEA0183devicestothedisplay’sNMEA
0183OUTPUT(Port1).Youcanconnectatotalof2NMEA0183
devicestothedisplay’sNMEA0183INPUT(Port2).
ItemDeviceCablecolorPortInput/outputPositive(+)/negative(-)
1White1InputPositive
2
Green
1InputNegative
3Yellow1
Output
Positive
4Brown1
Output
Negative
5
Orange/white
2InputPositive
6
Multifunctiondisplay
Orange/green
2InputNegative
44
e7/e7D/e95/e97/e125/e127/c95/c97/c125/c127
