Raymarine c97 Installation And Operation Handbook

Productdimensions
D12 269 -1
A
C
D
B
E
Item
e7/e7D
e95/e97/c95/
c97
e125/e127/
c125/c127
A
233mm(9.17in.)290mm(11.42
in.)
354mm(13.94
in.)
B
144mm(5.67in.)173mm(6.81in.)222mm(8.74in.)
C64mm(2.52in.)64mm(2.52in.)69mm(2.72in.)
D
160mm(6.29in.)160mm(6.29in.)160mm(6.29in.)
E
180mm(7.09in.)212mm(8.35in.)256mm(10.08
in.)
5.2Removingtherearbezel
Youmustremovetherearbezelbeforeush-mountingthedisplay.
1.Removethefrontbezel.Refertotheseparateinstructions
providedforthatprocedure.
D12 184 -2
* = e 7 / e 7D
*2
3
1
= c95 / c97 c125 / c127 / e 95 / e 97 / e 125 / e 127
2.Removethescrewsthatsecurethebezeltothedisplay.
3.Carefullyremovethebezelfromtherearofthedisplay,pulling
thebezelgentlyalongthe:
i.Outeredges-workfromthesidesupwardsandthenalong
thetopedge,ensuringthattheclipsarefullyreleasedfrom
thedisplay.
ii.Inneredges-ensurethatthebezeliscompletelyremoved
fromthedisplay.
Locationandmounting
53
