4.11NMEA2000connection
ThedisplaycanreceivedatafromNMEA2000devices(e.g.data
fromcompatibleengines).TheNMEA2000connectionismade
usingSeaT alk
ng
andappropriateadaptorcables.
YoucanEITHER:
•UseyourSeaTalk
ng
backboneandconnecteachNMEA2000
deviceonaspur,OR
•connectthedisplayonaspurintoanexistingNMEA2000
backbone.
Important:Youcannothave2backbonesconnectedtogether.
ConnectingNMEA2000equipmenttotheSeaTalk
ng
backbone
NMEA 200012V
D12 1 74 -2
1
2
4
3
SeaTalk
ng
1.12Vsupplyintobackbone.
2.SeaTalk
ng
backbone.
3.SeaTalk
ng
toDeviceNetadaptorcable.
4.NMEA2000equipment.
ConnectingthedisplaytoanexistingNMEA2000(DeviceNet)
backbone
D12 175 -2
32
4
1
1.Multifunctiondisplay.
2.SeaTalk
ng
toDeviceNetadaptorcable.
3.DeviceNet
ng
backbone.
4.NMEA2000equipment.
4.12Videoconnection
Avideodevicecanbeconnectedtothemultifunctiondisplayusing
thevideoconnectoronthepoweranddatacable.
Examplesofvideosourcesthatyoucanconnecttothedisplay
include:
•Videocamera.
•Thermalcamera.
•DVDplayer.
•Portabledigitalvideoplayer.
D12 1 78 -2
1
2
4
3
1.Multifunctiondisplay.
2.Poweranddatacable.
3.BNCvideoconnector(input1).
4.Videosource—forexample,videocamera.
46e7/e7D/e95/e97/e125/e127/c95/c97/c125/c127
