4.9SeaTalkconnection

YoucanconnectSeaT alkdevicestoyourmultifunctiondisplayusing

theoptionalSeaT alktoSeaTalk

converter.

D12 265 -1

SeaTalk

1.SeaTalkdevice.

2.SeaTalktoSeaTalk

converter.

3.Multifunctiondisplay.

SeaTalkaccessories

SeaTalkcablesandaccessoriesforusewithcompatibleproducts.

DescriptionPartNoNotes

NMEA/SeaTalk

converter

E85001

3m(9.8ft)SeaTalk

extensioncable

D285

5m(16.4ft)SeaTalk

extensioncable

D286

9m(29.5ft)SeaTalk

extensioncable

D287

12m(39.4ft)SeaTalk

extensioncable

E25051

20m(65.6ft)SeaTalk

extensioncable

D288

Cablesandconnections43
