4.4Networkconnections
YoucanconnectanumberofdigitaldevicestoyourmultifunctiondisplayusingtheNetworkconnector(s)attherearoftheunit.
Atypicalnetworkofdigitaldevicesmayinclude:
•Upto6Raymarinemultifunctiondisplays.
•SeaT alk
hs
orRayNetdigitaldevicessuchasaDigitalSounderModule(DSM)orradarscanner.
•Thermalcamera.
Note:Thedisplayincludeseither1(e7/e7Donly)or2networkconnectors,networksrequiringadditionalconnectionswillrequirea
Raymarinenetworkswitch.Thisisahubusedforconnectingmultipledevices.
TypicalSeaTalk
hs
network
D12 2 51-1
SeaTalk
hs
/ RayNet
SeaTalk
hs
/ RayNet
SeaTalk
hs
/ RayNet
SeaTalk
hs
/ RayNet
3 4221
1.Raymarinenetworkswitch.
2.Multifunctiondisplay.
3.Digitalradarscanner.
4.Thermalcamera.
Networkhardware
ItemPartnumberNotes
HS5SeaTalk
hs
network
switch
A80007
5–portswitchfor
networkconnection
ofmultipleSeaTalk
hs
devicesfeaturing
RayNetconnectors.
Equipmentwith
SeaTalk
hs
connectors
canalsobeconnected
viasuitableadaptor
cables.
SeaTalk
hs
network
switch
E55058
8–portswitchfornetwork
connectionofmultiple
SeaTalk
hs
devices.
SeaTalk
hs
crossover
coupler
E55060Enablesdirect
connectionofSeaTalk
hs
devicestosmaller
systemswhereaswitch
isnotrequired.Also
enablestheconnection
ofSeaTalk
hs
devices
toanHS5SeaTalk
hs
networkswitch(in
conjunctionwitha
RayNettoRJ45cable).
Networkcableconnectortypes
Thereare2typesofnetworkcableconnector—SeaTalk
hs
and
RayNet.
SeaTalk
hs
connector—usedforconnecting
SeaTalk
hs
devicestoaRaymarinenetworkswitch
viaSeaTalk
hs
cables.
RayNetconnector—usedforconnecting
RaymarinenetworkswitchesandSeaTalk
hs
devicestothemultifunctiondisplayviaRayNet
cables.Alsorequiredforconnectingacrossover
couplerifonlyonedeviceisbeingconnectedto
thedisplay’sNetworkconnector.
Networkcabletypes
Thereare2typesofSeaT alk
hs
networkcable—“patch”and
“network”.
•Patch—forconnectingthefollowingdevicestoaRaymarine
networkswitch:
–ThermalcameraviaPoEinjector.
–AdditionalRaymarinenetworkswitch.
–PCorlaptopusingVoyagerplanningsoftware.
•Network—forconnectingthefollowingdevicestoaRaymarine
networkswitch:
–DigitalSounderModule(DSM)sonar.
–SR100Siriusweatherreceiver.
–AdditionalcompatibleRaymarinemultifunctiondisplays.
RayNetnetworkcables
CablePartnumber
1m(3.28ft)RayNettoSeaTalk
hs
(RJ45)cable
A62360
2m(6.56ft)RayNettoRayNetcable
A62361
5m(16.4ft)RayNettoRayNetcable
A80005
Cablesandconnections35
