Raymarine c97 Installation And Operation Handbook

Resolution
800x480pixels(WVGA)
Viewingangle
•Left/Right:70degrees
•Top/Bottom:70/50degrees
e95/e97/c95/c97Displayspecication
Size
9in.
TypeTFTbacklitLED
Colordepth
8–bit
Resolution
800x480pixels(WVGA)
Viewingangle
•Left/Right:80degrees
•Top/Bottom:80/60degrees
e125/e127/c125/c127Displayspecication
Size
12in.
TypeTFTbacklitLED
Colordepth
8–bit
Resolution
1280x800pixels(WXGA)
Viewingangle
•Left/Right:80degrees
•Top/Bottom:80/60degrees
Dataconnections
Wiredconnections
NMEA01832xNMEA0183ports:
•NMEAport1:Inputandoutput,
4800/9600/38400baud
•NMEAport2:Inputonly,4800/
9600/38400baud
Network(SeaTalk
hs
)•e7/e7D=1xSeaTalk
hs
port.100
Mbits/s.RayNettypeconnection.
•e95/e97/c95/c97/e125/
e127/c125/c127=2xSeaTalk
hs
port.100Mbits/s.RayNettype
connection.
SeaTalk
ng
1xSeaTalk
ng
connection
Wirelessconnections
WiFi
802.11b/g
Bluetooth
AVRCP2.1+EDRpowerclass1.5
InternalGPSspecication
Channels
48
Hotstart<1second
Coldstart
36secondsinoptimalconditions
ReceiverICSensitivity
159dBmTracking
SatelliteBasedAidingSystem
(SBAS)
WAAS+EGNOS
Specialfeatures
ActiveJammingReduction
Operatingfrequency
1575.42MHz
SignalAcquisition
Automatic
AlmanacUpdateAutomatic
GeodeticDatumWGS-84,alternativesavailable
throughRaymarinedisplays.
UpdateRate1second
Antenna
Ceramicchip
Accuracy
•WithoutSBAS:<=15metres95%
ofthetime
•WithWAAS/EGNOS:<=5metres
95%ofthetime
Internalsonarspecication(e7D/e97/e127/
c97/c127displaysonly)
Operatingfrequencies50/83/200KHz
Transmitpower
Upto600WRMS,dependingon
transducer
Depthrange
Upto3000ft,dependingontransducer
Videospecication
SignaltypeComposite
Format
PALorNTSC
ConnectortypeBNC(female)
Electronicchartspecication
EmbeddedelectronicchartsNavionicsworldwidebasemap.
Compatiblechartcards
•NavionicsReadytoNavigate
•NavionicsSilver
•NavionicsGold
•NavionicsGold+
•NavionicsPlatinum
•NavionicsPlatinum+
•NavionicsFish’NChip
•NavionicsHotmaps
RefertotheRaymarinewebsite
(www.raymarine.com)forthelatestlist
ofsupportedchartcards.
Conformancespecication
Conformancecerticationappliestoalldisplayvariants
Conformance•NMEA2000certication
•WiFiAlliancecertication
•Bluetoothcertication
•Europe:1995/5/EC
•AustraliaandNewZealand:C-Tick,
ComplianceLevel2
•FCC47CFRpart15
•IndustryCanadaRSS210
Technicalspecication
257
