Installation and Service manual
Compass STD 22
98
Edition: July 1, 20053646/110 --233.DOC010302
Checking the DIP switch settings on the compass (see Figure 58):
Button B39
Button B38
DIP switch B37
Display
Button B39
Button B38 B37 DIP switch
Display
E10
Figure 58: Checks on the compass before putting into operation
All DIP switches in the “ON” position
Switch B 37
12345678
OPEN
OFF
ON
