Installation and Service manual
Compass STD 22 Compact
70
Edition: July 1, 2005
3646/110 --233.DOC010302
2.6.4.9 Function check on externally connected course receivers
Unscrew and remove the cover of the compass housing.
Button B39
Button B38
DIP switch B37
Display
Button B39
Button B38 B37 DIP switch
Display
E10
Figure 38: DIP switch B37 and button B38/B39
Initial status:
12345678
OPEN
Display
DIP switch B37
