Installation and Service manual
Compass STD 22 Compact
16
Edition: May 20, 2005
3646/110 --233.DOC010302
2.2 General information concerning installation of the STD 22 Compact
Compass
When fitting components, observe the following spacing:
Fit the compass enclosure so that the display can be viewed from above and the cover
of the enclosure can be removed (see also Dimensional Drawing 110--233.HP005).
To ensure fault-free operation of the STD 22Compact Compass, it is essential to follow
these directions, safety notes and installation instructions.
Instructions relating to cable cross-sections and earth connections must be adhered to.
The tools which are specified for installing the compass must be used.
Only original parts or parts approved by the manufacturer may be used in connection
with the STD 22 Compact Compass.
See also Cable Connection Diagram 110--233 HP010 for the STD 22 Compact Compass.
Gyro Compass should not be installed in oil--containing ambient air, not in surrounding in
vibration and should installed on a vibration--free platform.
Gyro compass should be installed on the ships‘ line (vertical and horizontal).
The installation of the power supply (AC/DC--Converter) should only be per-
formed by an experienced electrician.
The 24 VDC supply voltage should be engineered as a low--
security--voltage according to SELV.
