Compass
STD 22
Installation and Service manual
Compass STD 22 Compact
15
Edition: May 20, 2005 3646/110 --233.DOC010302
2 Preparing to install the STD 22 Compact Gyro Compass
To ensure that the STD 22 Compact Gyro Compass is installed and put into operation
correctly, these instructions must be followed in the order in which they appear.
It must not be installed or put into operation whilst at sea.
2.1 STD 22 Compact Compass – Scope of Supply
The scope of supply consists of:
-- Compass (110--233)
---- Outer sphere
---- Distilled water
---- Supporting liquid
---- Gyrosphere (111--006)
-- User manual for the STD 22 Compass
-- Installation and service manual for the STD 22 Compass
-- Tools and spare parts pack
---- Sealing rings
-- -- S u c t i o n c u p
---- Filling device
-- -- I n j e c t o r
Optional:
-- AC/DC converter (121--062)
-- Quick Settling Operator Unit (130--606)
-- Additional Output Box (146--103)
(Interface extension STEP/SSC)
