Installation and Service manual
Compass STD 22 Compact
56
Edition: July 1, 2005
3646/110 --233.DOC010302
2.6.4.6 Setting Channel 1 and Channel 2
Unscrew and remove the cover of the compass housing.
Button B39
Button B38
DIP switch B37
Display
Button B39
Button B38 B37 DIP switch
Display
E10
Figure 35: DIP switch B37 and buttons B38/B39
Initial status:
12345678
OPEN
Display
DIP switch B37
OFF
ON
