Installation and Service manual
Compass STD 22 Compact
32
Edition: July 1, 2005
3646/110 --233.DOC010302
1 2 3
4 56
78
9
10
1112
13
14
15
123456 78 9
101112
13
14
15
E10
Figure 15: Arrangement of plugs, terminal boards and fuses
1
Terminal L1 Power supply (24VDC)
2 Fuse E1 (T10A) Power supply (24VDC)
3 Plug B2 Output Channel1 Course Bus/NMEA
4 Fuse E2 (T1A) Channel1 +24V
5 Plug B3 Output Channel2 Course Bus/NMEA
6 Fuse E3 (T1A) Channel2 +24V
7 Plug B4 Output Course Bus
8 Fuse E4 (T1A) Course Bus +24V
9 Plug B5 Input (+24V/Set QS/ Pulse Log/Pulse Log Dir./NMEA Log/GPS--receiver)
10 Plug B6 Output (QS/SEC/System/Available)
11 Plug B7 CAN1 bus
1
2
Plug B8 CAN2 bus
12
Switch B32 for CAN1 bus terminating resistor E10
1
3
Terminal Board L2 24V connection to Power S upply PCB
13
Plug B8 CAN2 bus E10
1
4
Jumper B31 for the CAN2 bus terminating resistor
14
Switch B31 for the CAN2 bus terminating resistor E10
1
5
Jumper B32 for the CAN1 bus terminating resistor
15
Terminal Board L2 24V connection to Power S upply PCB E10
