Installation and Service manual
Compass STD 22
Compass STD 22 Compact
124
Edition: May 20, 2005
3646/110 --233.DOC010302
5.1.2 Adjustments of parameters (in ascending order of their appearance)
DIP--
switch
Step Display Function Push but-
ton B39
(right)
Push but-
ton B38
(left)
8 0 GYro Reading measured data of the gyro
1 Enco Encoder value choose display
2 ALEr Alignment error choose display
3 SEC SEC value choose display
4 Pbor 24 V ships mains after input filter 12--32 V choose display
5 Co14 14 V for 60 V inverter choose display
6 P--En 15 V for encoder supply choose display
7 P--60 60 V stabilized / ferrite transformer bridge choose display
8 Co19 19 V from ferrite transformer choose display
9 IndA Current of ferrite transformer bridge choose display
10 Co31 Voltage for heating circuit choose display
11 C°-- U Voltage on heater element choose display
12 -- C °-- Supporting liquid temperature choose display
13 Li--U Supporting liquid level choose display
14 Co73 73 V from ferrite transformer choose display
15 78--U 78 V stabilited for gyro AC converter choose display
16 GY--U Gyro supply voltage choose display
17 GY--A Gyro supply current choose display
18 Co15 15 V from ferrite transformer choose display
19 P--15 15 V stabilized choose display
20 P--24 24 V for pump AC converter choose display
21 U--Pu 24 V AC pump voltage choose display
22 A--Pu Pump current choose display
23 Ab9r Follow up voltager W1/W2 choose display
24 Pr--S Software sensor pcb choose display
25 Pr--P Software Power Supply PCB choose display
26 Pr61 Software MC1 outer sphere pcb choose display
27 Pr62 Software MC2 outer sphere pcb choose display
28 runY Operating years choose display
29 runh Operating hours choose display
30 0007 future purpose
31 0008 future purpose
7+8 0 E.L.01 Errors according to error logbook choose number of
errors
1 E.L.02--24 Errors according to error logbook choose number of
errors
Clear selected error logbook Hold 10s to clear
