Compass
STD 22
Installation and Service manual
Compass STD 22
Compass STD 22 Compact
125
Edition: May 20, 2005 3646/110 --233.DOC010302
DIP--
switch
Step Display Function Push but-
ton B38
(left)
Push but-
ton B39
(right)
6+7+8 0 UnCo Uncorrected heading choose display
1 FF Correction value SEC choose display
2 SPD Speed input value choose display
3 Br10 Latitude input choose display
4 Corr Corrected heading choose display
5 _roh Rough heading choose display
6 o_FF Correction value SEC with acc error choose display
7 _FF Correction value SEC without acc error choose display
8 _oF Acceleration error choose display
9 SCi Telegram traffic on serial interface choose display
10 SrCS Speed information source choose display
11 PULS Value from puls log choose display
12 vtG.S Value from GPS speed choose display
13 vtG.h Heading from GPS choose display
14 uhu Speed from NMEA telegram choose display
15 SPd.L Speed data transfer choose display
16 PoS Latitude in degrees choose display
17 ASPd Speed alarms choose display
18 PoSn Latitude data transfer choose display
19 APoS Latitude alarm choose display
20 nAUC Number of telegrams with checksum choose display
21 nAn1 1
st
table of NMEA requests choose display
22 nAn2 2
nd
table of NMEA requests choose display
23 nSGG Strings of GGA telegram choose display
24 nSGL Strings of GLL telegram choose display
25 nSLL Strings of SLL telegram choose display
26 nShu String of VHW telegram choose display
27 nStG String of VTG telegram choose display
28 nSbu String of VBW telegram choose display
29 Fb10 Software component SEC: Latitude choose display
30 FS10 Software component SEC: Speed choose display
31 FnSP Software component SEC: Ships speed vector choose display
32 FuTG Software component SEC: Speed over ground choose display
33 tiNE Time since activating SEC choose display
34 SCI Display s erial communication interface choose display
