5.1.4 Functional description of DIP switch settings (for general use)
Note: In the following tables, a flashing display on the compass is represented
like this.
Serial
No.
Indications Comments, Information
1 Normal operation
If the decimal point flashes during normal operation, a warning can be
displayed by means of the following procedure.
Switch B 37 (DIP switch)
12345678
OPEN
flashing
B38
B39
Indicatewarning1to4
(if a warning appears,
refer to operator manual)
Indicatewarning4to8
(if a warning appears,
refer to operator manual)
