Compass
STD 22
Installation and Service manual
Compass STD 22
73
Edition: May 20, 2005 3646/110 --233.DOC010302
3 Preparing to install the STD 22 Gyro Compass
To ensure that the STD 22 Gyro Compass is installed and put into operation correctly,
these instructions must be followed in the order in which they appear.
It must not be installed or put into operation whilst at sea.
3.1 STD 22 Compass – Scope of Supply
The scope of supply consists of:
-- Compass (110--233)
---- Outer sphere
---- Distilled water
---- Supporting liquid
---- Gyrosphere (111--006)
-- User manual for the STD 22 Compass
-- Installation and service manual for the STD 22 Compass
-- Tools and spare parts pack
---- Sealing rings
-- -- S u c t i o n c u p
---- Filling device
-- -- I n j e c t o r
The STD 22 Gyro Compass is used in conjunction with at least the following items of
equipment:
-- Distribution Unit 138--118 (separate manual)
-- Operator Unit 130--613 (separate manual)
