Raytheon Anschütz STD 22 Compact GYRO COMPASS Installation And Service Manual

Compass
STD 22
Installation and Service manual
Compass STD 22
Compass STD 22 Compact
3
Edition: May 20, 2005 3646/110 --233.DOC010302
1 General information
The STD 22 Compact Compass and the STD 22 Compass are identical gyro
compasses.
The difference between the two gyro compasses is that the STD 22 Gyro Compass can
be operated via a CAN bus system with an Operator Unit and a Distribution Unit.
In the case of the STD 22 Compact Gyro Compass, the CAN bus is not enabled.
The following diagrams provide an overview of the possible applications of the
STD 22 Compact and STD 22 Gyro Compasses.

Raytheon Anschütz STD 22 Compact GYRO COMPASS Specifications

General

Brand	Raytheon Anschütz
Model	STD 22 Compact GYRO COMPASS
Category	Compass
Language	English
